Fox F80 Rl Manual 1 2005 Fox Forx Owners Manual F80r F80rl F80rlt F80x F100r F100rl F100rlt F100x Float 130r Float 130rl Float 130rlc Talas R Talas Rl Talas Rlc.

• >Obtain an RA (Return Authorization) number and shipping address from FOX Racing Shox at 800.FOX.SHOX. Outside the USA, contact the appropriate International Service Center. >Mark the RA number and Return Address clearly on the outside of the package and send to FOX Racing Shox or your International Service Center with shipping charges pre-paid by the sender. • INSTALLING FOX 32MM FORX.

• CONGRATULATIONS! Thank you for choosing FOX 32MM FORX for your bicycle. In doing so, you have chosen the finest suspension fork in the world.

FOX Racing Shox products are designed, tested and manufactured by the finest professionals in the industry in Santa Cruz County, California, USA. Remove existing fork from the bicycle. Remove the crown race from the fork.

Measure the steerer tube length of the existing fork. Transfer this measurement to the FOX 32MM FORX steerer. Refer to stem manufacturer’s instructions to be sure there will be enough clamping surface for the stem. • Disc Disc brakes with 160 – 203 mm rotors can be used on FOX 32MM FORX. Do not use rotors larger than 203 mm. Jaa Atpl Exam Prep (new Cbt)download Free Software Programs Online. Install disc brakes and torque all fasteners according to manufacturer’s specifications. Install, route and check that all cables or hydraulic hoses are securely fastened to the lower leg and will not move during compression of the fork.

• Too slow and your If you increase your spring SLOWER (CW) fork will pack rate or air pressure, you will Slow Rebound down and ride need to slow down your harsh. Rebound Average Rebound (Factory setting) FASTER (CCW) Too fast and you If you decrease your spring Right-side knob will experience. • There are 12 clicks of adjustment. As a starting point, turn the knob all the way clockwise until it stops, then back off one click counterclockwise. X DAMPER EXPLAINED.

Easier Harder (CCW) The X dampers feature a lockout that is controlled by an inertia valve and will remain locked out until there is bump input ( CW ) from the trail. • TALAS travel 5.1 inches / 130mm TALAS: Adjustable between 130 – 90 mm features >Air spring pressure >Air spring pressure >Air spring pressure >Rebound >Rebound >Rebound >Low speed compression >Lockout >Lockout.

• To remove to expose the Schrader valve. Attach a FOX Racing Shox High Pressure Pump to the Schrader valve (see USING THE FOX HIGH PRESSURE AIR PUMP on page 8). Set your TALAS lever fully clockwise to the 130mm travel setting (9 o’clock position) and cycle the fork a few times so the fork is fully extended. • TALAS FLOAT F SERIES VANILLA CHANGING TRAVEL The TALAS features externally adjustable travel, from 5. Giggles Adult. 1” (130mm) to 3.5” (90mm), which is easily adjusted using the TALAS knob on top of the left fork leg. For safety reasons, it is recommended that travel adjustment be done while off the bike.
